You know our baseboard... you'll love our boilers!

350 Series

350 Series


  • Application: 19-gauge or 16-gauge steel front cover, 24-gauge back cover
  • Heights: 9-7/8" (one tier)
  • Lengths: 2' - 8'
  • Depth: 3-1/2"

350 Series baseboard combines, for the first time, the compactness and economy of baseboard with the high output and heavy-duty construction needed for “in-between” applications. Optional 1" and 1-1/4" copper / aluminum elements permit higher flow rates, longer series-loop runs and lower pump loads where required. With the 1-1/4" all-steel element, 350 Series is perfect for use in one or two pipe steam systems.


350-series

Product Features

  • Factory pre-assembled in individual cartons for rapid installations
  • Interchangeable heating elements
  • Room control damper optional
  • Double-bent aluminum fins won’t loosen
  • Expansion noises banished
  • Super-strong, dent-proof, kick-proof front panel
  • Stronger tubes for longer service
  • Extra-strength steel brackets
  • Finish: Nu-White (19 ga.); electro-gal.(16 ga.); choice of optional decorator colors
  • Choice of five Slant/Fins H-Element

How It Works

Slant/Fin baseboard provides gentle perimeter convection heating that blocks chilling drafts at the outside walls. Slant/Fin hot water baseboard heating surrounds your customers with heating comfort. Natural convection perimeter heating blocks chilling drafts at the outside walls where they originate. No annoying on-and-off blowing ducts. No dirt and germs blown through forced air system. Easy to zone for room by room comfort control. Ideal for use with high efficiency boilers.

you know swoosh logo

"Easy To Sell, Install, And Service."
